Explosion-proof distribution panel MAMX-02/03

The Explosion-proof distribution panel MAMX-02/03 is constructed for long-term performance in the most extreme hazardous conditions. Constructed of a high-grade aluminum alloy (ZL102) housing, it provides ultimate strength and protection. The panel is designed to provide electrical power with precision and accuracy and to keep the area around it free from internal sparks or excessive heat. It is specified with the latest Ex markings—Ex db IIC T6…T4 Gb and Ex tb IIIC T80°C…T135°C Db IP66—and comes with certification in the forms of ATEX, IECEx, and TR CU. They help demonstrate that the panel is safe to be used in an explosive atmosphere according to global safety standards.

The distribution panel contains a number of in-built control devices for full control and monitoring. It has a circuit breaker, AC contactor, PLC, transducer, soft starter, and other control devices. Due to the presence of such a large number of integrated control modules, it can control both the temperature regulation and power supply of electric heating systems, particularly in anti-freezing systems. It is designed to meet varied customer needs by delivering multiple instruments and program control modules. It accommodates a rated current of 1500A and can reliably withstand heavy loads in poor conditions.

Purpose-designed to accommodate various industrial applications, it is flexibly mounted. The panel supports various types of mounts including hanging and floor mounting. It also supports flexibility in terms of types of incoming cable from the standard rubber and plastic cables to armored cables, and heating cables.

Explosion-proof distribution panel MAMX-02/03 Product Features

• Enclosure Material: Aluminum alloy (ZL102)
• Ex Marks:
  • Ex db IIC T6…T4 Gb
  • Ex tb IIIC T80°C…T135°C Db IP66
• Certifications: ATEX, IECEx, TR CU
• Rated Current: Up to 1500A
• In-built Components:
  • Circuit Breaker
  • AC Contactor
  • Thermorelay
  • PLC
  • Transducer
  • Soft Starter
• Control Capabilities:
  • Integrated with various instruments and program control modules
  • Suitable for temperature maintenance of electric heating systems
  • Controls power supply for anti-freezing applications
• Installation Flexibility:
  • Supports hanging, floor-mounted, and bracket installations
  • Accepts ordinary rubber, plastic, armored, and heating cables
• Robust Construction:
  • Designed for hazardous environments
  • Withstands extreme conditions and heavy loads
• User Interface:
  • Can include indicators, push buttons, universal switches, or display instruments
• Versatility:
  • Meets different customer requirements with programmable control settings
• Safety:
  • Explosion-proof design to contain any internal faults
  • Minimizes the risk of ignition in explosive atmospheres

Areas of Applications

• Chemical Plants
• Oil Refineries
• Oil Exploitation Sites
• Offshore Oil Platforms
• Oil Tankers
• Military Installations
• Hazardous Industrial Areas
• Anti-freezing Electrical Heating Systems
• Power Distribution Networks in Explosive Environments

The frame of the Explosion-proof distribution panel MAMX-02/03 ensures safe connections and protection of the system during poor operating conditions. This panel is specifically designed to control electrical power in dangerous environments like chemical facilities, refineries, offshore platforms, oil tankers, and military installations. With its assured operation and high safety levels, it provides confidence and minimal downtime and maintenance.
